Bee Tackle Integrated Sonar Bait Boat BT7
5 Things To Know
- It carries up to 4kg of bait in its compact hull.
- Three sonar beams cover high, mid and low frequencies for scanning at different depths.
- The 680kHz beam reads from 0.3m to 30m with 1cm resolution.
- Sonar logs store timestamped readings for playback and transfer to the NDS Cloud.
- Advanced route planning requires the separately activated autopilot upgrade.
Product Information
The Bee Tackle Integrated Sonar Bait Boat BT7 is an integrated sonar bait boat for anglers who want to map their fishing grounds. Its sonar works with the boat and app, so you can review recorded scans at home and pinpoint a promising area before you get to the bank.
A 4kg bait capacity keeps the boat compact while carrying a substantial load.
Bee Tackle’s triple-beam sonar combines high, mid and low frequencies for different depths and coverage. The 680kHz beam reads from 0.3m to 30m with 1cm resolution, while the 200kHz beam reaches 100m and the 100kHz wide mode covers 0.8m to 30m.
It also maps weed shape, bottom hardness and depth changes as you scout.
Live Mapping builds bathymetric charts while the boat is scouting, and sonar logs store readings with timestamps for later playback. The single app controls both the sonar and boat, with cloud spot saving and replay-based spot marking included.
Advanced route planning is activated through the separate autopilot upgrade in the app.
Features and Specifications
| Feature | Details |
|---|---|
| Bait capacity | 4 kg |
| High-frequency beam | 680kHz, 0.3 to 30m range, 1cm resolution |
| Mid-frequency beam | 200kHz, 0.5 to 100m range, 2.4cm resolution |
| Low-frequency beam | 100kHz, 0.8 to 30m range, 2.4cm resolution |
| Sonar system | Integrated triple-beam sonar linked to the boat and app |
| Live mapping | Builds bathymetric charts while scouting |
| Bottom mapping | Weed discrimination, bottom-hardness mapping and precision depth tracking |
| Sonar logging | Timestamped recordings with playback and NDS Cloud transfer |
| Control app | Single-app control for sonar and bait boat |
| Cloud spots | Saves spots in the Bee Tackle cloud |
| Spot marking | Marks spots from live sonar data and replay |
| Autopilot | Advanced route planning activated through an in-app upgrade |
Price watch
Go to Total Fishing TackleGo to shopGet an email when the price drops
We'll email you when the price drops. Confirm your email once, then watch other products on this device with one click.
Frequently Asked Questions
How much bait can this boat carry?
The Bee Tackle Integrated Sonar Bait Boat BT7 has a 4kg bait capacity.
What sonar does this boat use?
It uses an integrated triple-beam sonar system with 680kHz, 200kHz and 100kHz beams.
How deep can this boat’s sonar read?
The 200kHz beam has a 0.5m to 100m range. The 680kHz and 100kHz beams each reach 30m.
Can I review sonar scans after fishing?
Yes. The app stores sonar readings with timestamps for playback, and scans can be reviewed at home.
Does this boat include route planning?
Advanced route planning is available through an autopilot upgrade purchased and activated in the app.
